Node-Core STM32F412 Dev Board

The Node Core is a development prototype board hosting the STM32F412 that out preforms most other boards at the same cost. The STM32F412 microcontrollers are the entry-level devices to the high-performance STM32F4 series and offer the best balance of dynamic power consumption (in Run mode) and processing performance, while integrating a high number of added-value features.

The STM32F412 MCUs deliver the performance of Cortex®-M4 core with floating point unit, running at 100 MHz, while achieving outstandingly low power consumption values in Run and Stop modes.

Key Features:
o- STM32F412CGU6
o- ARM Cortex M4 CPU
o- 1024K Flash Memory
o- 256K RAM
o- UART, I2C, SPI, ADC etc
o- UART over USB
o- 100Mhz max Clock Speed
o- 16Mhz External Clock
o- SWD Programming Interface
o- Arduino Compatible Pinout*
o- 40 Pin DIP Package

Kit Includes:
o- Main Board
o- Two 20way pin strips
